NO | Inspection Items | Unit | Standard Requirements |
1 | Density | g/cm3 | 1.25~1.35 |
2 | Melting Range | ºC | 210~240 |
3 | Melting Index (250ºC,2160g) | g/10min | 7.0~15 |
4 | Tensile Strength at yield | MPa | ≥50 |
5 | Elongation at yield | % | 4~10 |
6 | Elongation at break | % | ≥50 |
7 | Modulus of elasticity in tensile | MPa | ≥2100 |
8 | Shore Hardness | - | ≥70 |
9 | Modulus of elasticity in flexure | MPa | ≥2200 |
10 | moisture content | % | ≤0.05 |
11 | Izod impact strength 23ºC | KJ/m2 | ≥5 |
12 | Heat distortion temp 0.45Mpa | ºC | ≥170 |
Heat distortion temp 1.8Mpa | ºC | ≥55 | |
13 | Coefficient of volume Resistance | Ω.cm | ≥1.0* 1014 |
14 | Water absorptivity | % | ≤0.5 |
NO | Inspection Items | Unit | Standard Requirements |
1 | Density | g/cm3 | 1.25~1.35 |
2 | Melting Range | ºC | 210~240 |
3 | Melting Index (250ºC,2160g) | g/10min | 7.0~15 |
4 | Tensile Strength at yield | MPa | ≥50 |
5 | Elongation at yield | % | 4~10 |
6 | Elongation at break | % | ≥50 |
7 | Modulus of elasticity in tensile | MPa | ≥2100 |
8 | Shore Hardness | - | ≥70 |
9 | Modulus of elasticity in flexure | MPa | ≥2200 |
10 | moisture content | % | ≤0.05 |
11 | Izod impact strength 23ºC | KJ/m2 | ≥5 |
12 | Heat distortion temp 0.45Mpa | ºC | ≥170 |
Heat distortion temp 1.8Mpa | ºC | ≥55 | |
13 | Coefficient of volume Resistance | Ω.cm | ≥1.0* 1014 |
14 | Water absorptivity | % | ≤0.5 |
